Vakhmistrov's Circus

Zveno Combined Aircraft - The Projects, Development, Testing and Combat

Vakhmistrov's Circus : Zveno Combined Aircraft - The Projects, Development, Testing and Combat

Author : Mikhail Maslov

Paperback Helion & Company 248mm x 185mm 144 pages 180 b/w photos plus 16 sets of detailed scale drawings & 8 colour views

Out of print

The purpose of this publication is to provide readers with most complete history of combined aircraft designs created by Vladimir Vakhmistrov. The designer himself referred to his projects as ‘Zveno Aircraft’ (where the Russian word ‘Zveno’ stands for ‘Chain link’ or ‘Flight’ combat unit), adding the names of aircraft which were included in each configuration. Vakhmistrov was among the world’s pioneers in devising and implementing the attachment of small fighters under heavy bombers. The larger aircraft were thus able to carry the smaller ones to the target area, whereas the fighters, in their turn, after the separation from their ‘motherships’, acted as guards for the slow-speed giants. During the period from 1931 thru 1941, several configurations of this concept were created involving mass-produced TB-1 and TB-3 bombers, and I-4, I-5, I-Zet, and I-16 fighters, which were modified correspondingly in order to fit the task. Basing on Vakhmistrov's projects there were carried out the first in the world air connections of fighters under their bomber carriers. The most successful variant among all the created Zveno aircraft consisted of a four-engined Tupolev TB-3 bomber and two Polikarpov I-16 fighters attached under the bomber’s wing. The fighters carried two 250-kg bombs each and acted as a high-speed dive bombers after disconnection from the carrier plane. Several such aircraft, referred to as Zveno-SPB, were used operationally during the war by the Black Sea Fleet Air Force. Initially, three TB-3s with AM-34RN engines were allocated for re-equipment into Zveno-SPB which were taken into service by the 2nd Special Squadron of the 32nd Fighter Regiment, 62nd Aviation Brigade of the Black Sea Fleet Air Force stationed in Eupatoria. The order to begin combat application of the 32nd Regiment's combined aircraft was given on 22 July 1941, while the first air raid on port structures in Romania, the German ally, was made on 26 July. More than thirty combat missions were carried out till October 1941, and became one of the most successful operations of the Soviet aviation during the Great Patriotic War. Meanwhile, Vakhmistrov had a large number of other interesting projects and many of them remained on the designer's drawing board. More than 20 years were spent by the author on the historical research of the subject in the Russian archives. The book is extensively illustrated by the pictures from the author's archive, aircraft test reports, as well as specially prepared scale drawings and color side views.



“ … With pictures showing large, improvised wooden ramps built to allow the fighters to be moved up to their mounts on the upper wing of the bomber it could inspire some really interesting and impressive dioramas. A really interesting book and an intriguing topic.” Military Model Scene



"..... A very well-produced book and an intriguing subject which would be great to see reproduced in model form." Military Modelling



“ … Informative and entertaining at the same time…builders of Russian pre-war aviation, and modellers seeking more unusual subjects, will find this an invaluable reference.” Airfix Model World

Additional Information

Publisher
Helion & Company
ISBN
9781911096757
Date of Publication
January 2017
Binding
Paperback
Book Size
248mm x 185mm
Pages
144 pages
Images
180 b/w photos plus 16 sets of detailed scale drawings & 8 colour views
Language
English
Helion Book Code
HEL0739
